RE-BUILT KEYBOARD
PRE-BUILT KEYBOARD
1 x WH80 Keyboard
1 x 2.4G Dongle
1 x USB-C to USB-C Cable
1 x USB-C to USB-A adapter
1 x Keycap/Switch Puller
2 x Extra Toggle
1 x Quick Start Guide
(with FAQ & Instructions)
1 x Keyboard Pack
TECH SPECS
SPECIFICATION
- Layout
- ANSI 80%
- Number of Keys
- 83
- Switch Type
- High-Profile Magnetic Switches
- Stabilizer Type
- Plate Mounted
- Mount Type
- Gasket Mount
- Power-off Replaceable Switches Support
- Yes
- Backlight
- Top-emitting LED
- Backlight Modes
- 20
- Compatible System
- macOS/Windows/Android/iOS
- Operating Environment
- -10 to 50℃
CONNECTION
- Mode
- 24GHz, Wired (USB-C) or Bluetooth 5.0
- 2.4GHz Polling Rate
- 8000Hz
- Wired Polling Rate
- 8000Hz
- Bluetooth 5.0 Polling Rate
- 125Hz
MATERIALS
- Keycaps
- PBT
- Keyboard
- ABS
SIZE AND WEIGHT
- Long
- 357 mm (14.05 inches)
- Wide
- 144.7 mm (5.69 inches)
- Back Height
- 35.4 mm (1.39 inches)
- Front Height
- 21.7 mm (0.85 inches)
- Weight
- 1516 grams (3.34 pound)
- Type Angle
- 7º
* Note: 1. Due to technical limitations, renderings of keyboards published by NuPhy are not accurate representations of the final products.
